Product Description

The RCT BRK-TV32-75T Slim Tilt TV Wall Mount is designed for customers who need a strong, neat and space-efficient mounting solution for compatible medium- to large-format televisions.

It supports compatible flat and curved TVs from 32″ to 75″, with a maximum weight capacity of 75kg. Its slim 42mm profile keeps the television close to the wall, helping create a clean and modern installed appearance.

The mount supports VESA and universal mounting patterns from 100 × 100 up to 400 × 400, making it suitable for a wide range of compatible televisions used in homes, offices, boardrooms, hospitality environments and commercial installations.

A tilt range of 0° to -8° allows the screen angle to be adjusted for improved viewing comfort and reduced glare. The open-frame design supports ventilation and provides easier access to cables and television connections after installation.

The fixed wall plate is manufactured from steel and finished with a fine-texture black powder coating. The mount is strength tested to four times its approved load capacity and is suitable for installation on an appropriate solid wall or compatible double-stud structure.

Please check your television size, weight, VESA mounting pattern and wall type before ordering.

Key Features

• Slim tilting TV wall mount
• Suitable for compatible 32″ to 75″ televisions
• Supports compatible flat and curved TVs
• Maximum weight capacity of 75kg
• VESA and universal mounting-pattern support
• Supports VESA patterns from 100 × 100 up to 400 × 400
• Maximum mounting-hole pattern of 400 × 400
• Tilt range of 0° to -8°
• Slim 42mm profile for close-to-wall installation
• Fixed wall plate design
• Open-frame design supports ventilation and cable access
• Steel construction
• Fine-texture black powder-coated finish
• Strength tested to four times the approved load capacity
• Suitable for appropriate solid-wall installation
• Supports compatible 406mm / 16″ double-stud installation
• Suitable for home, office, boardroom and commercial displays
• Compact packaging suitable for storage and e-commerce distribution

Specifications

Compatibility

The RCT BRK-TV32-75T Slim Tilt TV Wall Mount is suitable for compatible:

• Flat-screen televisions
• Curved televisions
• 32″ to 75″ television sizes
• Televisions weighing 75kg or less
• TVs with VESA patterns from 100 × 100 up to 400 × 400
• Home entertainment installations
• Lounge and living-room television installations
• Bedroom television installations
• Office presentation displays
• Boardroom and meeting-room displays
• Hospitality and commercial display installations
• Close-to-wall television installations
• Installations requiring downward tilt adjustment

Please check your television size, weight, VESA mounting pattern and wall type before ordering.

Your television must:

• Have a screen size between 32″ and 75″
• Weigh 75kg or less
• Have a supported VESA or universal mounting pattern
• Support wall mounting
• Be suitable for installation with a tilting wall mount

The wall must be suitable for the combined weight of the television, wall mount and installation hardware.

Installation must be completed on an appropriate solid wall or compatible 406mm / 16″ double-stud structure. Professional installation is recommended where required for safe and secure mounting.

The supplied installation hardware may not be suitable for every television or wall type. Additional mounting hardware may be required depending on the television, wall material and installation environment.

What’s in the Box

• 1 × RCT BRK-TV32-75T Slim Tilt TV Wall Mount
• 1 × Components Package
• 1 × Installation Manual

Warranty

Limited 12 Month Warranty

Sustainability

The durable steel construction is designed for long-term use when the mount is correctly installed and used within its approved weight capacity.

The compact packaging supports more efficient storage, handling and distribution compared with larger packaging formats.
