RCT BRK-MTS01 Gas Spring Monitor Arm for 17–32" Screens

At a Glance

The RCT BRK-MTS01 is an adjustable gas spring monitor arm designed for one compatible flat or curved monitor between 17 and 32 inches.

It supports screens weighing between 2kg and 9kg, with VESA 75 × 75mm or 100 × 100mm mounting. Wide tilt, swivel, rotation and extension adjustment provide flexible positioning for a more comfortable and organised workstation.

Short Description

The RCT BRK-MTS01 supports one compatible 17–32-inch flat or curved monitor weighing between 2kg and 9kg.

Its gas spring mechanism, 450mm extension, portrait and landscape rotation, integrated cable management and included clamp and grommet mounting hardware make it suitable for home, office, study and gaming workstations.

Why Choose This RCT Monitor Arm

The BRK-MTS01 raises a compatible monitor away from the desk surface, creating additional workspace for a keyboard, docking station, documents and other equipment.

The gas spring mechanism allows the screen position to be adjusted for different working and viewing requirements.

Wide tilt, swivel and rotation ranges support varied viewing angles and compatible portrait or landscape screen layouts.

Both clamp and grommet mounting hardware are included, providing installation options for different compatible desks.

Recommended Use Cases

• Home-office workstations
• Business and corporate desks
• Single-screen productivity
• Reception workstations
• Study desks
• Gaming setups
• Content creation
• Financial and administrative applications
• Portrait monitor layouts
• Compact workstations
• Desks requiring additional usable surface space

Product Description

The RCT BRK-MTS01 Gas Spring Monitor Arm provides flexible positioning for one compatible monitor while helping free valuable desk space.

It supports flat and curved monitors from 17 to 32 inches, with a permitted screen weight between 2kg and 9kg. The monitor must use a compatible 75 × 75mm or 100 × 100mm VESA mounting pattern.

The gas spring arm supports tilt from -90° to +90°, swivel from -90° to +90°, and rotation from -180° to +180°. This allows compatible monitors to be positioned in portrait or landscape orientation.

The arm extends up to 450mm, allowing the monitor to be moved closer to or farther away from the user.

The BRK-MTS01 can be installed using the included desk clamp or grommet hardware. Clamp installation supports compatible desktops between 10mm and 80mm thick, while grommet installation supports compatible desktops between 10mm and 48mm thick.

Integrated cable-management covers help route monitor power and display cables along the arm for a cleaner workstation.

Key Features

• Single gas spring monitor arm
• Supports one compatible monitor
• Compatible with 17–32-inch screens
• Supports compatible flat monitors
• Supports compatible curved monitors
• Supports screen weights between 2kg and 9kg
• VESA 75 × 75mm compatible
• VESA 100 × 100mm compatible
• Tilt adjustment from -90° to +90°
• Swivel adjustment from -90° to +90°
• Screen rotation from -180° to +180°
• Supports portrait and landscape positioning
• Maximum arm extension of 450mm
• Desk-clamp mounting included
• Grommet mounting included
• Integrated cable management
• Steel and plastic construction
• Electrophoresis and powder-coated finish
• Suitable for home and professional workstations

Specifications

Screen Adjustment

The gas spring mechanism allows the monitor position to be adjusted for different users, tasks and viewing positions.

Supported adjustments include:

• Height and position adjustment
• Tilt from -90° to +90°
• Swivel from -90° to +90°
• Rotation from -180° to +180°
• Portrait or landscape positioning
• Arm extension up to 450mm

Gas spring tension can be adjusted using the included Allen key to suit the weight of the compatible monitor.

Installation Options

Desk-Clamp Installation

The included clamp supports compatible desktops between 10mm and 80mm thick.

The clamp attaches to the edge of the desk without requiring a mounting hole.

Grommet Installation

The included grommet hardware supports compatible desktops between 10mm and 48mm thick with a suitable mounting hole measuring between 10mm and 60mm in diameter.

The desktop must be strong enough to support the monitor, monitor arm and mounting hardware.

Compatibility

Please confirm all the following before ordering:

• The monitor is between 17 and 32 inches.
• The monitor weighs between 2kg and 9kg.
• The monitor uses a 75 × 75mm or 100 × 100mm VESA mounting pattern.
• The desk is strong enough to support the complete installation.
• The desktop thickness is compatible with the selected mounting method.
• The desk has a suitable mounting hole when using the grommet installation.
• Connected power and display cables are long enough for the required arm movement.

Available adjustment may vary according to monitor size, monitor weight, cable length, desk position and nearby equipment.

Installation and Safety Notes

Install the monitor arm on a strong, stable desktop and tighten all mounting hardware securely.

Adjust the gas spring tension to suit the monitor’s weight. Hold the arm horizontally while making the adjustment.

Position the arm so the monitor does not extend beyond the rear edge of the desk in a way that could destabilise the installation.

Do not exceed the maximum supported screen weight of 9kg.

What’s in the Box

• RCT BRK-MTS01 gas spring monitor arm
• Extension arm section
• VESA mounting plate
• Desk mounting base
• Desk-clamp mounting hardware
• Grommet mounting hardware
• Cable-management covers
• Monitor mounting screws and washers
• 4mm Allen key
• 5mm Allen key
• Installation manual

Warranty

One-Year RCT Limited Warranty
