RCT BRK-TV23-65M 23–65" Full-Motion TV Wall Mount - 30kg

At a Glance

The RCT BRK-TV23-65M is an adjustable full-motion wall mount designed for compatible flat and curved televisions from 23 to 65 inches.

It supports televisions weighing up to 30kg, accommodates VESA mounting patterns up to 400 × 400mm and provides extension, tilt and swivel adjustment for flexible viewing.

The mount retracts to approximately 60mm from the wall and extends up to 382mm when additional positioning or viewing-angle adjustment is required.

Short Description

The RCT BRK-TV23-65M is a full-motion wall mount for compatible 23–65-inch flat and curved televisions weighing up to 30kg.

It supports VESA patterns from 100 × 100mm to 400 × 400mm, extends from 60mm to 382mm and provides +3° to -10° tilt together with ±90° swivel adjustment.

Why Choose This RCT TV Mount

The BRK-TV23-65M provides a flexible and economical mounting solution for televisions that need to be viewed from different positions in a room.

Its articulated arm allows the television to extend away from the wall, swivel left or right and tilt vertically.

When additional adjustment is not required, the mount can retract to approximately 60mm from the wall, helping conserve space and maintain a tidy installed appearance.

Recommended Use Cases

• Lounges and entertainment rooms
• Bedroom televisions
• Flat-screen televisions
• Compatible curved televisions
• Gaming setups
• Home offices
• Boardrooms and meeting rooms
• Office display installations
• Reception areas
• Hospitality environments
• Retail displays
• Multi-position viewing
• Corner and angled television installations

Product Description

The RCT BRK-TV23-65M is a full-motion television wall mount designed for compatible screens measuring between 23 and 65 inches.

It supports televisions weighing up to 30kg and accommodates VESA mounting patterns ranging from 100 × 100mm to 400 × 400mm.

The articulated arm provides an adjustable wall profile of 60–382mm. This allows the television to remain closer to the wall when retracted or extend outward when swivel adjustment, cable access or a different viewing position is required.

The mount provides a tilt range from +3° to -10° and can swivel up to 90° in either direction. The actual available swivel angle depends on the television’s width, installation position and surrounding clearance.

A detachable mounting panel allows the VESA plate to be attached to the television before being secured to the articulated arm.

Four extension adapter arms are included for televisions requiring larger VESA mounting patterns.

Integrated cable management helps route compatible power and signal cables along the articulated arm.

The mount is manufactured from steel with a fine-texture black powder-coated finish. It is designed for installation on a structurally suitable solid wall or compatible single-stud structure.

Key Features

• Designed for compatible 23–65-inch televisions
• Supports flat televisions
• Supports compatible curved televisions
• Maximum supported television weight of 30kg
• VESA compatibility from 100 × 100mm to 400 × 400mm
• Full-motion articulated arm
• 60–382mm adjustable wall profile
• +3° to -10° tilt adjustment
• +90° to -90° swivel adjustment
• Retracts closer to the wall
• Extends outward for flexible positioning
• Detachable television mounting panel
• Four extension adapter arms
• Integrated cable management
• Fixed wall plate
• Steel construction
• Fine-texture black finish
• Powder-coated surface
• Suitable for solid-wall installation
• Suitable for compatible single-stud installation
• Television and wall-mounting hardware included
• Installation manual included
• No anti-theft function

Specifications

Supported VESA Patterns

The BRK-TV23-65M supports the following mounting-hole patterns:

• 100 × 100mm
• 100 × 200mm
• 200 × 100mm
• 200 × 200mm
• 300 × 200mm
• 300 × 300mm
• 400 × 200mm
• 400 × 300mm
• 400 × 400mm

The television’s horizontal and vertical mounting-hole spacing must match one of the supported configurations.

Full-Motion Adjustment

The mounting system provides:

• Minimum wall profile: 60mm
• Maximum wall extension: 382mm
• Upward tilt: Up to 3°
• Downward tilt: Up to 10°
• Left swivel: Up to 90°
• Right swivel: Up to 90°

The actual swivel range may be reduced by:

• Television width
• Television thickness
• Wall position
• Nearby furniture
• Adjacent walls
• Cable length
• Connected devices
• Other surrounding obstructions

Extension and Retraction

The articulated arm can retract to approximately 60mm from the wall and extend outward up to approximately 382mm.

Extending the television can provide:

• Greater left and right swivel movement
• Improved access to rear connections
• Flexible viewing from different seating positions
• Easier positioning in corner installations

Cables must have sufficient slack to accommodate the full extension and swivel range.

Flat and Curved Television Support

The BRK-TV23-65M supports compatible flat and curved televisions, provided that the television’s weight, VESA configuration and mounting requirements fall within the supported specifications.

The four supplied adapter arms are used for the larger supported VESA configurations.

The television’s rear surface must allow the mounting plate and adapter arms to sit securely without obstructing ventilation openings, ports or other components.

Cable Management

The integrated cable-management clip helps route compatible cables along the articulated mounting arm.

When arranging cables:

• Leave sufficient slack for full extension
• Allow enough movement for left and right swivel adjustment
• Avoid pinching cables between moving components
• Keep cables away from sharp edges
• Do not place excessive strain on television connectors
• Check that cables do not limit the mount’s movement
• Keep ventilation openings unobstructed

Compatibility

The RCT BRK-TV23-65M is suitable for a television only when all the following requirements are met:

• Screen size is between 23 and 65 inches
• Television weight does not exceed 30kg
• Mounting-hole pattern matches a supported VESA configuration
• Mounting pattern does not exceed 400 × 400mm
• The television supports wall mounting
• The supplied M6 or M8 screws are suitable for the television
• The wall is structurally suitable
• Sufficient clearance is available for extension and swivel
• Connected cables accommodate the required movement

Screen size alone does not confirm compatibility. The television’s weight, VESA pattern, mounting-screw requirements and rear-panel design must also be checked.

Wall Compatibility

The mount is designed for installation on:

• A structurally suitable solid masonry wall
• A suitable structural timber stud
• Another compatible structural surface capable of supporting the combined load

The mount must not be attached directly to unsupported drywall, plasterboard or another non-structural surface.

Wall fasteners must be appropriate for the supporting wall material and the combined weight of the mount and television.

Installation Requirements

Installation requires suitable tools, accurate measurements and a structurally sound mounting surface.

Before installation:

• Confirm the television’s weight
• Measure the television’s VESA mounting holes
• Check the required mounting-screw size
• Check the permitted screw insertion depth
• Identify the wall construction
• Locate the structural stud where applicable
• Check for concealed wiring and plumbing
• Confirm sufficient space for extension and swivel
• Ensure cables are long enough for the required movement
• Check that all mounting components are present and undamaged

Larger televisions should be lifted and installed by at least two people.

Professional installation is recommended.

Installation and Safety Notes

• Do not exceed the maximum supported weight of 30kg
• Do not install the mount on an unsuitable or damaged wall
• Do not attach the mount directly to unsupported drywall
• Use suitable fasteners for the wall material
• Use at least two people to lift and position larger televisions
• Never lift a television by its screen
• Do not use mounting screws that are too long
• Do not use screws that are too short to engage securely
• Do not overtighten screws fitted into the television
• Confirm that the detachable mounting panel is properly secured
• Keep cables clear of moving joints
• Ensure ventilation openings remain unobstructed
• Check the bracket and fasteners periodically
• Keep unused screws and small components away from children

Incorrect installation may result in equipment damage, serious injury or both.

What’s in the Box

• RCT BRK-TV23-65M Full-Motion TV Wall Mount
• Detachable Television Mounting Panel
• 4 × VESA Extension Adapter Arms
• Adapter-Arm Screws and Nuts
• Installation Spanner
• Wall-Mounting Bolts
• Wall Anchors
• Wall-Mounting Washers
• M6 Television Mounting Screws
• M8 Television Mounting Screws
• Television Mounting Washers
• Installation Manual

Warranty

12-Month Limited Warranty

Warranty coverage does not include damage caused by incorrect installation, overloading, an unsuitable mounting surface, misuse, unauthorised modification or failure to follow the installation instructions.
