RCT BRK-TV43-95T 43–95" Slim Tilt TV Wall Mount - 75kg

At a Glance

The RCT BRK-TV43-95T is a heavy-duty slim tilt wall mount designed for compatible flat and curved televisions from 43 to 95 inches.

It supports televisions weighing up to 75kg, accommodates VESA mounting patterns up to 800 × 400mm and provides up to 8 degrees of downward tilt.

Its slim 42mm wall profile keeps the television close to the wall, while the open-frame design provides ventilation and easier access to cables and television connections.

Short Description

The RCT BRK-TV43-95T is a slim tilt wall mount for compatible 43–95-inch flat and curved televisions weighing up to 75kg.

It supports VESA patterns up to 800 × 400mm, provides 0° to -8° tilt adjustment and positions the television approximately 42mm from the wall.

Why Choose This RCT TV Mount

The BRK-TV43-95T provides a strong, space-saving solution for mounting a large television close to the wall.

Its heavy-duty steel construction supports compatible televisions weighing up to 75kg, while the adjustable vertical rails accommodate multiple common VESA mounting patterns.

The downward tilt function is useful when the television is positioned above normal eye level, while the slim fixed-wall design creates a clean and unobtrusive installed appearance.

Recommended Use Cases

• Lounges and entertainment rooms
• Large-screen home televisions
• Flat-screen televisions
• Curved televisions
• Boardrooms and meeting rooms
• Reception areas
• Training facilities
• Hospitality environments
• Retail displays
• Office presentation screens
• Commercial display installations
• Above-eye-level television mounting
• Close-to-wall installations

Product Description

The RCT BRK-TV43-95T is a heavy-duty tilting television wall mount designed for compatible screens measuring between 43 and 95 inches.

It supports televisions weighing up to 75kg and has been strength tested to four times its approved load capacity.

The mounting system supports VESA and compatible universal mounting-hole patterns from 200 × 200mm to 800 × 400mm.

Its fixed-wall design positions the television approximately 42mm from the wall, creating a slim and modern appearance while retaining access to compatible cables and connections through the open mounting structure.

The mount provides a tilt range from 0° to -8°, allowing the bottom of the television to move away from the wall for improved viewing when the screen is mounted above normal eye level.

Detachable vertical mounting rails attach to the back of the television before it is lifted onto the wall plate. Pull-release cords allow the lower rail locks to be released when the television needs to be removed.

The mount is manufactured from steel and ABS with a fine-texture black powder-coated finish.

It can be installed on a structurally suitable solid wall or compatible double-stud structure with stud spacing of 406mm, 450mm or 600mm.

Key Features

• Designed for compatible 43–95-inch televisions
• Supports flat televisions
• Supports compatible curved televisions
• Maximum supported television weight of 75kg
• VESA compatibility up to 800 × 400mm
• Slim 42mm wall profile
• 0° to -8° downward tilt
• Heavy-duty steel and ABS construction
• Fine-texture black finish
• Powder-coated surface
• Fixed wall-plate design
• Detachable television mounting rails
• Pull-release rail-locking system
• Open-frame construction
• Provides easier cable access
• Supports ventilation around the television
• Hook-on bubble level included
• Suitable for solid-wall installation
• Supports compatible double-stud structures
• Compatible with 406mm, 450mm and 600mm stud spacing
• Strength tested to four times the approved load capacity
• Installation hardware included
• Installation manual included

Specifications

Supported VESA Patterns

The BRK-TV43-95T supports the following mounting-hole patterns:

• 200 × 200mm
• 300 × 200mm
• 400 × 200mm
• 300 × 300mm
• 400 × 300mm
• 400 × 400mm
• 600 × 400mm
• 800 × 400mm

The television’s horizontal and vertical mounting-hole spacing must match one of the supported patterns.

Tilt Adjustment

The BRK-TV43-95T provides a tilt range of:

• Maximum upright position: 0°
• Maximum downward tilt: 8°

The downward tilt function is useful when the television is installed above normal seated or standing eye level.

This mount does not provide left or right swivel adjustment.

Slim Wall Profile

The mount positions a compatible television approximately 42mm from the wall.

The actual clearance around the television may vary depending on:

• Television shape
• Rear-panel design
• Spacer requirements
• Cable connectors
• Curved television construction
• Recessed mounting points

Right-angled or low-profile cable connectors may be required where the television’s ports face directly towards the wall.

Flat and Curved Television Support

The BRK-TV43-95T supports compatible flat and curved televisions.

The supplied spacers can assist with televisions featuring:

• Curved rear panels
• Recessed mounting points
• Uneven rear surfaces
• Raised areas surrounding the mounting holes

The correct screw length and spacer combination must be selected carefully.

Screws that are too long may damage the television, while screws that are too short may not engage securely.

Compatibility

The RCT BRK-TV43-95T is suitable for a television only when all the following requirements are met:

• Screen size is between 43 and 95 inches
• Television weight does not exceed 75kg
• Mounting-hole arrangement matches a supported VESA configuration
• Mounting pattern does not exceed 800 × 400mm
• The rear mounting surface can accommodate the supplied rails
• The mounting screws are suitable for the television
• The supporting wall is structurally suitable
• The installation position allows the required downward tilt
• Sufficient space is available for cables and connectors

Screen size alone does not confirm compatibility. The television’s weight, VESA pattern, mounting-screw requirements and rear-panel design must also be checked.

Wall Compatibility

The mount is designed for installation on:

• A structurally suitable solid masonry wall
• A compatible double-stud wall structure
• Double studs positioned at approximately 406mm, 450mm or 600mm centres

The mount must not be attached directly to unsupported drywall, plasterboard or another non-structural surface.

The installation hardware must be suitable for the wall material and combined weight of the television and mount.

Installation Requirements

Installation requires suitable tools, accurate measurements and a structurally sound supporting wall.

Before installation:

• Confirm the television’s weight
• Measure the television’s VESA mounting holes
• Check the required mounting-screw diameter
• Check the permitted screw insertion depth
• Identify the wall construction
• Locate supporting studs where applicable
• Check for concealed wiring and plumbing
• Confirm that the installation position provides adequate ventilation
• Check that cables and connectors will fit behind the television
• Ensure all mounting components are present and undamaged

Installation of a large television should be completed by at least two people.

Professional installation is recommended.

Installation and Safety Notes

• Do not exceed the maximum supported weight of 75kg
• Do not install the mount on an unsuitable or damaged wall
• Do not attach the mount directly to unsupported drywall
• Use the correct fasteners for the supporting wall material
• Use at least two people to lift and position the television
• Never lift the television by its screen
• Do not use mounting screws that are too long
• Do not use screws that are too short to engage securely
• Do not overtighten screws fitted into the television
• Confirm that the mounting rails are properly secured
• Check that the lower locking mechanism has engaged
• Keep cables away from sharp edges
• Ensure the television’s ventilation openings remain unobstructed
• Check the mount and fasteners periodically
• Keep unused screws and small components away from children

Incorrect installation may result in equipment damage, serious injury or both.

What’s in the Box

• RCT BRK-TV43-95T Tilt TV Wall Mount
• 2 × Detachable Television Mounting Rails
• 2 × Decorative Wall-Plate Covers
• Hook-On Bubble Level
• 4mm Allen Key
• Wall-Mounting Bolts
• Wall Anchors
• Wall-Mounting Washers
• M6 Television Mounting Screws
• M8 Television Mounting Screws
• Television Mounting Washers
• Short Spacers
• Long Spacers
• Installation Manual

Warranty

12-Month Limited Warranty

Warranty coverage does not include damage caused by incorrect installation, overloading, an unsuitable mounting surface, misuse, unauthorised modification or failure to follow the installation instructions.
