Synology DS1525neo+ 5-Bay Scalable Business NAS

At a Glance

• 5-bay neo+ business NAS
• AMD Ryzen 4-core / 8-thread processor
• 4GB DDR4 non-ECC memory, expandable to 32GB
• Dual built-in 2.5GbE
• Optional 10GbE upgrade
• Two M.2 NVMe slots
• Expandable from 5 to 15 drive bays
• 3-Year Synology Hardware Warranty

Important: Storage drives are not included.

Short Description

The Synology DS1525neo+ is a versatile 5-bay business NAS that delivers the core performance, networking and expansion capabilities of the DS1525 platform with a more affordable 4GB non-ECC memory configuration.

It provides dual 2.5GbE, optional 10GbE, M.2 NVMe support and expansion to 15 drive bays for businesses that want a storage platform capable of growing with their requirements.

Why Choose This Synology

A More Affordable Starting Point

The neo+ configuration starts with 4GB non-ECC DDR4 memory while retaining the DS1525 platform's Ryzen processor, network connectivity and expansion capabilities.

Dual 2.5GbE Networking

Two 2.5GbE ports provide fast network performance from day one.

Upgrade to 10GbE

Add the compatible E10G22-T1-Mini Network Upgrade Module when your infrastructure requires additional bandwidth.

Five Bays with Serious Growth Potential

Start with five main SATA bays and add up to two DX525 expansion units to increase total drive capacity to fifteen bays.

Built-In M.2 NVMe

Two M.2 slots support compatible NVMe SSDs for cache or dedicated SSD storage pools.

Best For

• Small and medium businesses
• Business file storage
• Centralised backup
• Team collaboration
• Professional media storage
• Multi-site synchronisation
• Virtualisation
• Surveillance
• Businesses expecting substantial storage growth

Product Description

The Synology DiskStation DS1525neo+ is a 5-bay scalable NAS built on the same core hardware platform as the DS1525+.

It features an AMD Ryzen V1500B processor with 4 cores and 8 threads at 2.2GHz.

The neo+ model includes 4GB DDR4 non-ECC memory as standard and supports expansion to 32GB.

Five hot-swappable main bays support compatible 3.5-inch SATA HDDs and 2.5-inch SATA SSDs. Two M.2 2280 NVMe slots support compatible Synology SSDs for caching or storage pools.

Dual 2.5GbE ports provide built-in networking, while a dedicated PCIe Gen3 x2 network-upgrade slot supports the E10G22-T1-Mini 10GbE module.

Up to two DX525 expansion units can increase total drive capacity from five to fifteen bays.

Storage drives are sold separately.

Key Features

• 5-bay desktop NAS
• AMD Ryzen V1500B
• 4GB DDR4 non-ECC memory
• Expandable to 32GB
• Dual 2.5GbE
• Optional 10GbE
• Two M.2 NVMe slots
• M.2 SSD cache and storage pools
• Expandable to 15 drive bays
• Synology Hybrid RAID
• Btrfs / ext4
• 3-year warranty

What Do I Need With This NAS?

Required

• Compatible storage drives

Optional

• Additional memory
• M.2 NVMe SSDs
• E10G22-T1-Mini 10GbE module
• Up to two DX525 expansion units
• Additional Surveillance Station licences

Compatible Storage

Plus Series HDD

• HAT3300-4T
• HAT3300-6T
• HAT3320-8T
• HAT3310-12T
• HAT3310-16T
• HAT3320-20T

Enterprise HDD

• HAT5320-4T
• HAT5320-8T
• HAT5300-12T
• HAT5310-16T
• HAT5320-20T
• HAT5320-24T

Enterprise SATA SSD

• SAT5221-480G
• SAT5221-960G
• SAT5221-1920G
• SAT5221-3840G
• SAT5210-7000G

M.2 NVMe SSD

• SNV3410-400G
• SNV5420-400G
• SNV5420-800G
• SNV5420-1600G

Compatibility Note: Confirm exact drive and firmware compatibility against Synology's current DS1525neo+ Compatibility List.

Compatible Upgrades & Accessories

Memory

• D4NS01-4G
• D4ES04-4G
• D4ES03-8G
• D4ES03-16G

Maximum memory: 32GB

Storage Expansion

• DX525 × up to 2

Maximum total drive bays: 15

Networking

• E10G22-T1-Mini – 10GbE Network Upgrade Module

Surveillance Station

Includes 2 Surveillance Station device licences.

Supports up to 40 IP cameras at 1080p under Synology's test configuration.

Specifications

What’s in the Box

• Synology DS1525neo+ Main Unit × 1
• Accessory Pack × 1
• AC Power Adapter × 1
• AC Power Cord × 1
• RJ-45 LAN Cable × 2

Warranty

3-Year Synology Hardware Warranty

Eligible for extension to five years with EW201 in Africa, subject to regional availability.

Sustainability

• RoHS Compliant
