RCT BRK-TV50-100M 50–100" Full-Motion TV Wall Mount - 65kg

At a Glance

The RCT BRK-TV50-100M is an ultra-slim heavy-duty full-motion wall mount designed for compatible flat and curved televisions from 50 to 100 inches.

It supports televisions weighing up to 65kg, accommodates VESA mounting patterns up to 800 × 600mm and provides extension, tilt and swivel adjustment for flexible viewing.

The mount retracts to just 35mm from the wall and extends up to 259mm when additional positioning is required.

Short Description

The RCT BRK-TV50-100M is a heavy-duty full-motion wall mount for compatible 50–100-inch flat and curved televisions weighing up to 65kg.

It supports VESA mounting patterns up to 800 × 600mm, extends from 35mm to 259mm and provides +3° to -15° tilt together with ±30° swivel adjustment.

Why Choose This RCT TV Mount

The BRK-TV50-100M combines a slim wall profile with the adjustment required for larger televisions.

When retracted, the television can sit approximately 35mm from the wall for a clean, low-profile appearance. The full-motion mechanism can then extend up to 259mm, allowing the screen to be angled towards different viewing positions.

Its wide mounting frame supports compatible televisions up to 100 inches, while the detachable mounting rails help simplify television installation.

Recommended Use Cases

• Lounges and entertainment areas
• Large-screen home televisions
• Flat-screen televisions
• Curved televisions
• Boardrooms and meeting rooms
• Reception areas
• Training facilities
• Hospitality environments
• Retail displays
• Commercial display installations
• Flexible multi-position viewing
• Low-profile wall-mounted installations

Product Description

The RCT BRK-TV50-100M is an ultra-slim heavy-duty television wall mount designed for compatible screens measuring between 50 and 100 inches.

Its steel and plastic construction supports televisions weighing up to 65kg and has been strength tested to three times the approved load capacity.

The mount supports VESA and compatible universal mounting-hole arrangements ranging from 200 × 200mm to 800 × 600mm.

Its articulated mounting mechanism provides a wall profile of 35–259mm. This allows the television to remain close to the wall when retracted or move forward when swivel adjustment or cable access is required.

The mount provides a tilt range from +3° to -15°, helping reduce reflections or improve the vertical viewing angle. It also provides up to 30° of swivel adjustment in either direction, subject to the television’s size and available wall clearance.

Detachable vertical mounting rails attach to the television before the screen is lifted onto the wall-mounted frame. An integrated locking mechanism helps secure the television rails to the mounting structure.

Integrated cable-management clips help organise compatible power and signal cables behind the installed television.

The BRK-TV50-100M can be installed on a structurally suitable solid wall or a compatible double-stud structure with 406mm or 450mm stud spacing.

Key Features

• Designed for compatible 50–100-inch televisions
• Supports flat televisions
• Supports compatible curved televisions
• Maximum supported television weight of 65kg
• VESA compatibility up to 800 × 600mm
• Ultra-slim 35mm minimum wall profile
• Extends up to 259mm from the wall
• Full-motion articulated mechanism
• +3° to -15° tilt adjustment
• +30° to -30° swivel adjustment
• Freely adjustable screen tilt
• Heavy-duty steel and plastic construction
• Matte-black powder-coated finish
• Detachable television mounting rails
• Fixed wall plate
• Integrated cable management
• Compatible with solid-wall installation
• Supports compatible 406mm or 450mm double-stud structures
• Strength tested to three times the approved load capacity
• Mounting hardware included
• Installation manual included

Specifications

Supported VESA Patterns

The BRK-TV50-100M supports the following mounting-hole patterns:

• 200 × 200mm
• 200 × 300mm
• 300 × 200mm
• 200 × 400mm
• 400 × 200mm
• 300 × 300mm
• 300 × 400mm
• 400 × 300mm
• 600 × 200mm
• 500 × 300mm
• 400 × 400mm
• 600 × 300mm
• 500 × 400mm
• 400 × 600mm
• 600 × 400mm
• 700 × 400mm
• 800 × 400mm
• 600 × 600mm
• 800 × 500mm
• 800 × 600mm

The television’s exact horizontal and vertical mounting-hole spacing must match one of the supported patterns.

Full-Motion Adjustment

The mounting mechanism provides:

• Wall profile: 35–259mm
• Upward tilt: Up to 3°
• Downward tilt: Up to 15°
• Left swivel: Up to 30°
• Right swivel: Up to 30°

The available swivel angle may be reduced when mounting a particularly wide television or when clearance is restricted by nearby walls, furniture or other objects.

The tilt mechanism can be tension-adjusted if the television does not remain at the selected angle.

Flat and Curved Television Support

The BRK-TV50-100M can support compatible flat and curved televisions.

The supplied spacer set can assist with televisions that have:

• Curved rear panels
• Recessed mounting points
• Uneven rear surfaces
• Raised sections surrounding the mounting holes

The correct screw length and spacer combination must be selected carefully. Screws that are too long may damage the television, while screws that are too short may not secure it safely.

Cable Management

Integrated cable-management clips help route compatible power and signal cables behind the television.

When arranging cables:

• Leave sufficient slack for the full extension range
• Allow enough movement for left and right swivel adjustment
• Avoid pinching cables inside the mounting mechanism
• Keep cables away from sharp edges and moving joints
• Do not place excessive strain on television connectors
• Ensure the television’s ventilation openings remain unobstructed

Compatibility

The RCT BRK-TV50-100M is suitable for a television only when all the following requirements are met:

• Screen size is between 50 and 100 inches
• Television weight does not exceed 65kg
• Mounting-hole pattern matches a supported VESA configuration
• Mounting pattern does not exceed 800 × 600mm
• The rear mounting surface can accommodate the supplied rails
• The supporting wall is structurally suitable
• The supplied or manufacturer-approved screws fit the television
• Sufficient wall clearance is available for extension and swivel
• Connected cables allow the required range of movement

Screen size alone does not confirm compatibility. The television’s weight, VESA pattern, rear-panel design and mounting-screw requirements must also be checked.

Wall Compatibility

The mount is designed for installation on:

• A structurally suitable solid masonry wall
• A compatible double-stud structure
• Double studs positioned at 406mm or 450mm centres

The mount must not be fixed directly to unsupported drywall, plasterboard or another non-structural surface.

Wall anchors and mounting hardware must be appropriate for the wall construction and the combined weight of the mount and television.

Installation Requirements

Installation requires accurate measurement, suitable tools and a structurally sound mounting surface.

Before installation:

• Confirm the television’s weight
• Measure the television’s VESA mounting holes
• Confirm the required mounting-screw size and depth
• Identify the wall construction
• Locate the supporting studs where applicable
• Check for concealed wiring, plumbing and other services
• Confirm that the selected position provides adequate ventilation
• Ensure sufficient clearance for extension, tilt and swivel
• Confirm that all mounting components are present and undamaged

Installation of a large television should be completed by at least two people.

Professional installation is recommended.

Installation and Safety Notes

• Do not exceed the maximum supported weight of 65kg
• Do not install the mount on an unsuitable or damaged wall
• Use the correct fasteners for the supporting wall material
• Do not attach the mount directly to unsupported drywall
• Use at least two people to lift and position the television
• Never lift a television by its screen
• Do not use mounting screws that are too long
• Do not use screws that are too short to engage securely
• Do not overtighten screws fitted into the television
• Confirm that the mounting rails are properly locked in place
• Keep cables clear of moving components
• Ensure all fasteners are securely tightened
• Check the installation periodically
• Keep unused screws and small components away from children

Incorrect installation may result in equipment damage, serious injury or both.

What’s in the Box

• RCT BRK-TV50-100M Full-Motion TV Wall Mount
• 2 × Detachable Television Mounting Rails
• Cable-Management Components
• Integrated Spirit Level
• 3mm Allen Key
• Wall-Mounting Bolts
• Wall Anchors
• Wall-Mounting Washers
• M6 Television Mounting Screws
• M8 Television Mounting Screws
• Television Mounting Washers
• Short Spacers
• Long Spacers
• Installation Manual

Warranty

12-Month Limited Warranty

Warranty coverage does not include damage caused by incorrect installation, an unsuitable mounting surface, overloading, misuse, unauthorised modification or failure to follow the installation instructions.
