Synology RackStation RS1626xs+ 4-Bay Rackmount NAS

The Synology RackStation RS1626xs+ is a scalable 4-bay 1U enterprise NAS with an Intel Xeon processor, 16GB ECC memory, dual 10GbE, two M.2 NVMe slots and redundant power supplies.

Product Description

The Synology RS1626xs+ is designed for enterprise file storage, business backup, collaboration, virtualisation and surveillance.

It features a six-core Intel Xeon D-1726 processor, 16GB DDR4 ECC memory expandable to 64GB and four hot-swappable SATA drive bays.

Dual 10GbE ports provide high-speed connectivity and network redundancy. Two built-in M.2 NVMe slots support SSD caching, while the PCIe 4.0 expansion slot supports selected network and Fibre Channel adapters.

Storage capacity can be expanded to 16 drives with an optional RX1225RP Expansion Unit.

Storage drives, M.2 SSDs, memory upgrades, expansion units, PCIe cards and rack rails are not included.

Key Features

• Compact 4-bay 1U rackmount NAS
• Intel Xeon D-1726 processor
• Six CPU cores and twelve threads
• 2.9GHz base and up to 3.5GHz turbo frequency
• Hardware encryption engine
• 16GB DDR4 ECC RDIMM memory
• Memory expandable to 64GB
• Four hot-swappable SATA drive bays
• Supports 3.5-inch SATA HDDs and 2.5-inch SATA SSDs
• Two M.2 2280 NVMe slots
• Supports compatible NVMe SSD caching
• Expandable to 16 drives with one RX1225RP
• Two built-in 10GbE RJ-45 ports
• Dedicated out-of-band management port
• PCIe 4.0 x8 expansion slot
• Supports selected 10GbE and 25GbE network cards
• Supports selected Fibre Channel adapters
• Redundant power supply system
• Supports RAID F1 and RAID 0, 1, 5, 6 and 10
• Supports Btrfs internal volumes
• Supports Synology High Availability
• Includes two Surveillance Station device licences
• Supports up to 75 compatible IP cameras
• Five-year Synology hardware warranty

Recommended Use Cases

• Enterprise and departmental file storage
• Branch-office storage
• Server and virtual-machine backup
• Virtualisation and Fibre Channel storage
• Private-cloud collaboration
• High-speed 10GbE environments
• M.2 NVMe SSD caching
• Surveillance recording
• Business continuity and disaster recovery
• Expandable rackmount storage

Specifications

Compatibility Note

Confirm that all storage drives, M.2 SSDs, memory modules, expansion units, PCIe cards and rack accessories are compatible with the Synology RS1626xs+ before ordering.

The RS1626xs+ supports one optional RX1225RP Expansion Unit, increasing the total number of drive bays from four to sixteen.

Compatible memory expansion uses Synology D4ER02-16G modules. All installed memory modules must be identical and use the same model number.

The built-in M.2 slots support compatible NVMe SSD caching and do not support hot-swapping.

The PCIe slot supports selected Synology 10GbE and 25GbE network cards and compatible Fibre Channel adapters.

This model supports RAID F1 but does not support Synology Hybrid RAID.

Volumes larger than 108TB require additional memory and a supported storage configuration. A 1PB volume requires 64GB memory and RAID 6.

Installation in a compatible 4-post rack requires an optional Synology RKS-04 sliding rail kit.

Available capacity will be reduced by RAID, formatting, system partitions and file-system data. RAID does not replace an independent backup.

What’s in the Box

• Synology RackStation RS1626xs+ main unit
• Accessory pack
• 2 × C13 to C14 power cords
• Front cover

Storage drives, M.2 SSDs, memory upgrades, RX1225RP Expansion Unit, PCIe cards and rack rails are not included.

Warranty

Five-year Synology hardware warranty.

Sustainability

• RoHS compliant
• HDD hibernation support
• Scheduled power-on and power-off support
• Replaceable system fans and redundant power supplies
• Expandable memory, storage and networking may extend the system’s useful operating life
