AOC 22E2HM 21.5-Inch Full HD VA Monitor - 75Hz HDMI and VGA
AOC 22E2HM 21.5-Inch Full HD VA Monitor - 75Hz HDMI and VGA
The AOC 22E2HM is a 21.5-inch Full HD monitor featuring a VA panel, a refresh rate of up to 75Hz and a three-sided frameless design. Its 3000:1 contrast ratio, Flicker-Free technology, Low Blue Mode and VESA mounting support make it suitable for office work, study and multimedia use.
Product Description
The AOC 22E2HM combines Full HD image quality, wide viewing angles and a compact frameless design for home, office and study environments.
Its 21.5-inch VA panel displays a 1920 × 1080 Full HD resolution at up to 75Hz through HDMI. VGA connectivity supports compatible legacy computers and other analogue video sources.
The VA panel provides a 3000:1 typical contrast ratio and wide 178-degree horizontal and vertical viewing angles. This helps maintain consistent picture quality while providing deeper dark tones than many conventional entry-level displays.
The three-sided frameless design provides a clean appearance and makes the monitor suitable for multi-screen desk configurations.
AOC Flicker-Free technology helps reduce visible screen flicker, while Low Blue Mode is designed to reduce short-wave blue-light output during extended viewing sessions.
AOC Clear Vision can upscale supported standard-definition sources for improved sharpness. Screen+ software allows users to divide the desktop into organised working areas for easier multitasking.
The monitor includes HDMI 1.4 and VGA inputs, a 3.5mm headphone output and a 100mm × 100mm VESA mounting pattern.
Key Features
• 21.5-inch Full HD display
• 1920 × 1080 resolution
• VA panel technology
• Up to 75Hz refresh rate
• 4ms grey-to-grey response time
• 3000:1 typical contrast ratio
• 20 million:1 dynamic contrast ratio
• 250cd/m² typical brightness
• Wide 178-degree viewing angles
• 16.7 million display colours
• Three-sided frameless design
• HDMI 1.4 input
• VGA input
• 3.5mm headphone output
• AOC Flicker-Free technology
• AOC Low Blue Mode
• AOC Clear Vision image enhancement
• Screen+ multitasking software support
• HDR Mode visual processing
• 100mm × 100mm VESA mounting support
• Tilt-adjustable stand
• No built-in speakers
Specifications
| FIELD | DETAILS |
|---|---|
| Product Code | AOC-22E2HM |
| Model | 22E2HM |
| Product Type | Full HD Monitor |
| Screen Size | 21.5 inches |
| Display Type | Flat |
| Panel Type | VA |
| Resolution | 1920 × 1080 Full HD |
| Aspect Ratio | 16:9 |
| Maximum Refresh Rate | 75Hz |
| Response Time | 4ms GtG |
| Typical Brightness | 250cd/m² |
| Static Contrast Ratio | 3000:1 |
| Dynamic Contrast Ratio | 20 Million:1 |
| Viewing Angle | 178° horizontal / 178° vertical |
| Display Colours | 16.7 million |
| Colour Gamut | NTSC 96% CIE 1976 / sRGB 116% CIE 1931 |
| Pixel Pitch | 0.2493mm |
| Effective Viewing Area | 478.656mm × 260.28mm |
| Flicker-Free Technology | Yes |
| Low Blue Mode | Yes |
| Clear Vision | Yes |
| Screen+ Support | Yes |
| HDMI | 1 × HDMI 1.4 |
| VGA | 1 × VGA |
| Audio Output | 1 × 3.5mm headphone output |
| HDCP Support | HDMI HDCP 1.4 |
| USB Hub | No |
| Built-In Speakers | No |
| VESA Mount | 100mm × 100mm |
| Tilt Adjustment | -5° to 23° |
| Power Input | 100V to 240V AC, 50Hz / 60Hz |
| Typical Power Consumption | 18W |
| Dimensions Without Stand | 492.1mm × 290.2mm × 51.1mm |
| Dimensions With Stand | 492.1mm × 367.6mm × 187.7mm |
| Packaging Dimensions | 565mm × 381mm × 126mm |
| Weight Without Stand | 2.24kg |
| Weight With Stand | 2.61kg |
| Gross Packaged Weight | 3.83kg |
| Colour | Black |
| Regulatory Approvals | CB, CE, FCC, RoHS and TÜV Low Blue Light |
| Warranty | Three-Year Limited Warranty |
What’s in the Box
• 1 × AOC 22E2HM Monitor
• 1 × Monitor stand and base
• 1 × Power cable
• Product documentation
Signal cable contents are not confirmed and may vary by regional package.
Warranty
Three-Year AOC Limited Warranty
