ASUS
ASUS ExpertCenter P500 SFF P500SV Core 7 16GB 512GB Desktop
R 16,999.00
Estimated delivery between September 15 and September 19.
R 16,999.00
R 16,999.00
The ASUS ExpertCenter P500 SFF P500SV-C716512G0W is a compact 8.6-litre business desktop powered by the Intel Core 7 240H processor, 16GB DDR5 memory and a 512GB PCIe 4.0 NVMe SSD. With Wi-Fi 6, Bluetooth 5.4, Gigabit Ethernet, flexible expansion and a 3-year onsite Next Business Day warranty, it is designed for dependable business productivity and professional office environments.
Product Description
The ASUS ExpertCenter P500 SFF P500SV-C716512G0W combines strong business performance, a compact small form factor design and flexible expansion for professional workspaces.
This exact configuration features an Intel Core 7 240H processor, 16GB DDR5 SO-DIMM memory, a 512GB M.2 NVMe PCIe 4.0 SSD and integrated Intel Graphics. It ships with Windows 11 Home Single Language.
The Intel Core 7 240H processor features 10 cores and 16 threads, 24MB cache and a maximum processor frequency of up to 5.2GHz.
The installed 16GB DDR5 memory operates at 5600MT/s, while two SO-DIMM slots provide support for up to 64GB of system memory.
Storage is provided through a 512GB M.2 2280 NVMe PCIe 4.0 SSD. The system includes two M.2 2280 storage connectors, one 3.5-inch drive bay and two SATA 6Gb/s ports for additional compatible storage.
The compact 8.6-litre chassis supports flexible placement in professional workspaces and incorporates a tool-free design to simplify maintenance and upgrades. The broader P500SV platform is designed to meet MIL-STD-810H testing standards and includes ASUS business-grade security features.
Connectivity includes USB 3.2 Gen 1 Type-C, USB 3.2 Gen 1 Type-A, HDMI 1.4, DisplayPort 1.4, Gigabit Ethernet and 7.1-channel high-definition audio.
Wi-Fi 6 and Bluetooth 5.4 provide wireless connectivity, while discrete TPM 2.0, HDD user password protection and a Kensington Security Slot support business security requirements.
Key Features
- Intel Core 7 240H processor
- 10 processor cores
- 16 processing threads
- 24MB processor cache
- Up to 5.2GHz maximum processor frequency
- Integrated Intel Graphics
- 16GB DDR5 SO-DIMM memory
- DDR5-5600 memory speed
- Two DDR5 SO-DIMM slots
- Up to 64GB supported memory
- 512GB M.2 NVMe PCIe 4.0 SSD
- Two M.2 2280 storage connectors
- One 3.5-inch drive bay
- Two SATA 6Gb/s ports
- 8.6-litre small form factor chassis
- Tool-free upgrade design
- PCIe 4.0 x16 expansion slot operating at x8
- USB 3.2 Gen 1 Type-C
- USB 3.2 Gen 1 Type-A
- HDMI 1.4
- DisplayPort 1.4
- Gigabit Ethernet
- Wi-Fi 6
- Bluetooth 5.4
- 7.1-channel high-definition audio
- Discrete TPM 2.0
- Kensington Security Slot
- HDD user password protection
- MIL-STD-810H tested platform
- 180W 80 PLUS Bronze power supply
- Wired keyboard and mouse included
- Windows 11 Home Single Language
- 3-Year Onsite Next Business Day Warranty
Recommended Use Cases
- Business productivity
- Office applications
- Corporate workstations
- Small and medium businesses
- Education
- Call centres
- Administrative work
- Remote and hybrid work
- Multi-display workspaces
- General professional computing
Specifications
| FIELD | DETAILS |
|---|---|
| Product Code | P500SV-C716512G0W |
| ASUS Model Number | 90PF05A1-M01650 |
| Series | ExpertCenter P500 SFF |
| Model | P500SV |
| Product Type | Small Form Factor Desktop PC |
| Form Factor | Small Form Factor |
| Chassis Volume | 8.6L |
| Operating System | Windows 11 Home Single Language |
| Processor | Intel Core 7 240H |
| Processor Base Frequency | 2.5GHz |
| Maximum Processor Frequency | Up to 5.2GHz |
| Processor Cores | 10 |
| Processor Threads | 16 |
| Processor Cache | 24MB |
| CPU Cooling | Air Cooler |
| Graphics | Intel Graphics |
| Installed Memory | 16GB DDR5 SO-DIMM |
| Memory Speed | 5600MT/s |
| Memory Slots | 2 × DDR5 SO-DIMM |
| Maximum Supported Memory | Up to 64GB |
| Storage | 512GB M.2 2280 NVMe PCIe 4.0 SSD |
| M.2 Storage Connectors | 2 × M.2 2280 |
| Drive Bay | 1 × 3.5-Inch |
| SATA | 2 × SATA 6Gb/s |
| Optical Drive | None |
| Expansion Slot | 1 × PCIe 4.0 x16, operating at x8 |
| Wi-Fi Expansion | 1 × M.2 Connector for Wi-Fi |
| Wireless | Wi-Fi 6 802.11ax, Dual-Band 1×1 |
| Bluetooth | Bluetooth 5.4 |
| Ethernet | Intel Gigabit Ethernet 10/100/1000Mbps |
| Front USB-C | 1 × USB 3.2 Gen 1 Type-C, 5Gbps |
| Front USB-A | 2 × USB 3.2 Gen 1 Type-A, 5Gbps |
| Front Audio | 1 × 3.5mm Combo Audio Jack |
| Rear USB-A | 4 × USB 2.0 Type-A |
| HDMI | 1 × HDMI 1.4 |
| DisplayPort | 1 × DisplayPort 1.4 |
| Network Port | 1 × RJ45 Gigabit Ethernet |
| Rear Audio | Microphone, Line-Out, Line-In |
| Audio | 7.1-Channel High Definition Audio |
| Power Supply | 180W, 80 PLUS Bronze, 228W Peak |
| Security | Discrete TPM 2.0, Kensington Security Slot, HDD User Password Protection |
| Dimensions | 93 × 296 × 309mm |
| Weight | 5.06kg |
| Colour | Gray |
Compatibility
Designed for supported Windows 11 applications and professional business software.
External displays can be connected through HDMI 1.4 and DisplayPort 1.4.
The system supports up to 64GB DDR5 memory across two SO-DIMM slots.
Storage expansion is supported through two M.2 2280 storage connectors, one 3.5-inch drive bay and two SATA 6Gb/s ports.
The PCIe 4.0 x16 expansion slot operates at PCIe 4.0 x8 on this configuration.
Compatible USB peripherals can be connected through the front USB 3.2 Gen 1 Type-C and Type-A ports or the rear USB 2.0 Type-A ports.
What’s in the Box
- ASUS ExpertCenter P500 SFF P500SV-C716512G0W Desktop
- Wired USB Keyboard
- Wired USB Optical Mouse
- Power Cord
- Warranty Card
- Quick Start Guide
- 3.5-Inch HDD Assembly Kit
- Monitor NOT Included
Warranty
3-Year Onsite Service
