EcoFlow WAVE 3 Portable Air Conditioner with Heating

The EcoFlow WAVE 3 Portable Air Conditioner delivers powerful portable cooling and heating for caravans, camper vans, tents, cabins, compact rooms, mobile workspaces and off-grid environments.

With 6100 BTU cooling capacity, 6800 BTU heating capacity, a temperature setting range of 16°C to 30°C, five operating functions, smart app control and noise levels starting from approximately 44dB, the WAVE 3 provides flexible climate control without requiring permanent installation.

The unit can operate from a compatible AC wall outlet, EcoFlow portable power station or optional EcoFlow WAVE 2 or WAVE 3 Add-On Battery.

The WAVE 3 does not include a built-in battery. The Add-On Battery, portable power station and other charging accessories are sold separately unless specifically included in a bundle.

Key Features

• 6100 BTU cooling capacity
• 6800 BTU heating capacity
• Cooling capacity of 1800W
• Heating capacity of 2000W
• Temperature setting range from 16°C to 30°C
• Drops the temperature by up to 8°C in approximately 15 minutes under specified test conditions
• Raises the temperature by up to 9°C in approximately 15 minutes under specified test conditions
• Cooling, heating, fan, automatic and dehumidification functions
• Sleep Mode with noise levels starting from approximately 44dB
• Automatic temperature-management function
• Pet Care function with app notifications
• Water-tank level and drainage alerts
• EcoFlow App control through Wi-Fi and Bluetooth
• Air volume of up to 330m³ per hour
• Supports optional wireless operation for approximately 2 to 8 hours with a compatible EcoFlow Add-On Battery
• Compatible with the EcoFlow WAVE 3 Add-On Battery
• Compatible with the EcoFlow WAVE 2 Add-On Battery
• Compatible with selected EcoFlow portable power stations through a supported XT150 connection
• Insulated exhaust duct and multiple adapter covers included
• Compact portable design weighing approximately 15.6kg
• IPX4-rated water resistance
• 24-month limited warranty

Product Overview

The EcoFlow WAVE 3 Portable Air Conditioner provides portable cooling and heating for locations where a fixed air-conditioning system may not be practical.

It delivers 6100 BTU of cooling capacity and 6800 BTU of heating capacity, making it suitable for compact spaces such as caravans, camper vans, tents, cabins, small rooms, mobile offices and temporary work areas.

Under EcoFlow’s specified test conditions, the WAVE 3 can lower the temperature by up to 8°C in approximately 15 minutes or raise the temperature by up to 9°C in approximately 15 minutes.

The unit supports a temperature setting range of 16°C to 30°C, allowing it to be used for both cooling and heating throughout different seasons.

An included insulated exhaust duct directs hot or cold exhaust air away from the conditioned space. Three exhaust duct adapter covers support different installation arrangements.

The WAVE 3 can operate directly from a compatible AC wall outlet. Optional portable operation is available through a compatible EcoFlow WAVE Add-On Battery or supported EcoFlow portable power station.

The WAVE 3 itself does not contain an internal battery.

Cooling and Heating Performance

Cooling Capacity

• 6100 BTU
• 1800W cooling capacity
• Rated cooling input power:
• Approximately 690W using AC power
• Approximately 640W using compatible DC battery power
• Cooling efficiency:
• Approximately 2.6 using AC power
• Approximately 2.8 using compatible DC battery power

Heating Capacity

• 6800 BTU
• 2000W heating capacity
• Rated heating input power:
• Approximately 645W using AC power
• Approximately 606W using compatible DC battery power
• Heating efficiency:
• Approximately 3.1 using AC power
• Approximately 3.3 using compatible DC battery power

Actual cooling and heating performance depends on the space size, insulation, outdoor temperature, humidity, duct installation, airflow, power source and operating mode.

Operating Functions

Cooling Mode

Provides active cooling between 16°C and 30°C.

The exhaust duct should be positioned correctly to remove hot exhaust air from the conditioned area.

Heating Mode

Provides active heating between 16°C and 30°C.

Cold exhaust air must be directed away from the conditioned area using the included duct system.

Automatic Function

Automatically adjusts operation according to the selected temperature and surrounding conditions.

The unit can switch between supported operating functions to help maintain a more consistent temperature.

Fan Mode

Circulates air without actively cooling or heating the space.

Fan Mode can be used when air movement is required without compressor operation.

Dehumidification Function

Helps reduce moisture in the surrounding air.

This function may be useful during humid or rainy conditions. Collected water must be drained according to the operating instructions.

Sleep Mode

Sleep Mode reduces operating noise to approximately 44dB under suitable conditions.

Actual noise levels vary according to the selected fan speed, compressor operation, temperature and installation environment.

Pet Care Function

The EcoFlow App allows a temperature threshold to be configured for Pet Care monitoring.

When the temperature exceeds the configured threshold, the WAVE 3 can begin cooling and send a notification through the EcoFlow App.

Pet Care Mode is an additional convenience function and should not replace responsible supervision, ventilation, reliable power or appropriate animal-care precautions.

Water Drain Alert

The EcoFlow App can notify the user when the internal water tank approaches its capacity.

The included drainage pipe can be connected when manual or continuous drainage is required.

Product Specifications

• Product Name: EcoFlow WAVE 3 Portable Air Conditioner
• Product Type: Portable Air Conditioner and Heater
• Cooling Capacity: 1800W / 6100 BTU
• Heating Capacity: 2000W / 6800 BTU
• Temperature Setting Range: 16°C to 30°C
• Air Volume: Up to 330m³/h
• Rated Cooling Input, AC: Approximately 690W
• Rated Cooling Input, DC: Approximately 640W
• Rated Heating Input, AC: Approximately 645W
• Rated Heating Input, DC: Approximately 606W
• Maximum AC Input: 820W
• AC Input Voltage: 100V to 240V, 50/60Hz
• Maximum Add-On Battery Input: 700W
• Refrigerant: R290
• Refrigerant Quantity: 112g
• Operating Temperature: 5°C to 50°C
• Noise Level: Approximately 44dB to 58dB
• Water Resistance: IPX4
• Remote Control: EcoFlow App
• Connectivity: Wi-Fi and Bluetooth
• Supported Wi-Fi: 2.4GHz and 5GHz
• Net Weight: Approximately 15.6kg
• Dimensions: 519mm × 297mm × 336mm
• Warranty: 24-month limited warranty

Power Options

The EcoFlow WAVE 3 can be powered using:

• A compatible AC wall outlet
• A compatible EcoFlow WAVE 3 Add-On Battery
• A compatible EcoFlow WAVE 2 Add-On Battery
• Selected EcoFlow portable power stations with a supported XT150 connection

The power source must support the WAVE 3’s voltage and input-power requirements.

Important Battery Note

The EcoFlow WAVE 3 does not have a built-in battery.

Wireless or off-grid operation requires a separately sold:

• EcoFlow WAVE 3 Add-On Battery
• EcoFlow WAVE 2 Add-On Battery
• Compatible EcoFlow portable power station
• Supported cable or adapter where required

The Add-On Battery shown in selected product images is not included with the standalone WAVE 3 unless the listing specifically states that the product is a bundle.

Optional WAVE 3 Add-On Battery

When paired with the separately sold EcoFlow WAVE 3 Add-On Battery, the system provides:

• 1024Wh battery capacity
• LiFePO₄ battery chemistry
• Approximately 4000 cycles to at least 80% capacity
• Approximately 2 to 8 hours runtime depending on mode and conditions
• Up to 400W solar input
• AC, solar, vehicle and EcoFlow Alternator Charger charging options
• USB-A output up to 18W
• USB-C output up to 140W

Battery runtime varies according to cooling or heating demand, temperature, fan speed, Eco Mode settings, ambient conditions and battery condition.

WAVE 2 Add-On Battery Compatibility

The EcoFlow WAVE 2 Add-On Battery is compatible with the EcoFlow WAVE 3.

Important differences between the two battery models include:

• WAVE 2 Add-On Battery capacity: approximately 1159Wh
• WAVE 3 Add-On Battery capacity: 1024Wh
• WAVE 2 battery chemistry: NCM
• WAVE 3 battery chemistry: LiFePO₄
• WAVE 2 estimated cycle life: approximately 800 cycles
• WAVE 3 estimated cycle life: approximately 4000 cycles to 80% capacity
• Solar charging through XT60 is supported directly by the WAVE 3 Add-On Battery

EcoFlow Portable Power Station Compatibility

The WAVE 3 can operate from selected EcoFlow portable power stations that support the required output and connection method.

Compatibility depends on:

• Available AC or DC output
• XT150 port availability
• Required cable or adapter
• Portable power station capacity
• Maximum supported output
• Battery charge level
• Firmware compatibility

Confirm compatibility with the specific EcoFlow power station before ordering.

Not every EcoFlow RIVER or DELTA product supports direct XT150 operation.

EcoFlow App Control

The WAVE 3 can be monitored and controlled through the EcoFlow App using Wi-Fi or Bluetooth.

Supported app functions may include:

• Turning the unit on or off
• Selecting cooling or heating mode
• Selecting fan and dehumidification functions
• Adjusting the target temperature
• Adjusting fan speed
• Activating Sleep Mode
• Configuring Pet Care settings
• Viewing water-drain alerts
• Monitoring operating status
• Viewing connected battery information
• Installing compatible firmware updates

App functions may vary according to firmware version, mobile device, network availability and regional services.

Exhaust Duct Installation

Portable air conditioners require correct airflow separation to operate efficiently.

The included insulated exhaust duct should be installed so that unwanted hot or cold exhaust air is directed outside the conditioned space.

Depending on the selected mode:

• Cooling Mode produces cool supply air and warm exhaust air
• Heating Mode produces warm supply air and cold exhaust air

The exhaust outlet should not discharge back into the same area being cooled or heated.

Poor duct installation may significantly reduce performance.

Installation Guidance

For improved operation:

• Place the WAVE 3 on a stable, level surface
• Keep the air inlet and outlets unobstructed
• Install the exhaust duct securely
• Keep the duct as straight and short as reasonably possible
• Seal gaps around windows, doors or vehicle openings
• Keep the unit away from direct sunlight where possible
• Allow sufficient clearance for airflow
• Do not cover the unit during operation
• Keep the unit away from dust, sand and loose debris
• Do not operate the unit on its side or upside down

Drainage Information

Water may collect inside the unit during cooling, heating or dehumidification, depending on humidity and operating conditions.

When drainage is required:

• Connect the included drain pipe
• Follow the water-drain instructions in the user guide
• Hold the drainage control for the required period to begin automatic drainage
• Drain the unit before transport or storage
• Keep the unit level during operation
• Do not tilt or turn the unit upside down

Failure to drain accumulated water before moving the product may result in leakage or internal damage.

Room-Size and Performance Note

EcoFlow’s rapid cooling and heating claims were tested in a controlled space of approximately 10m³.

Actual performance depends on:

• Room or enclosure size
• Ceiling height
• Insulation
• Direct sunlight
• Outdoor temperature
• Number of occupants
• Heat-producing appliances
• Door and window openings
• Duct length and installation
• Air leakage
• Humidity
• Selected operating mode

The WAVE 3 is primarily intended for compact and temporary spaces. It should not automatically be treated as a replacement for a permanently installed residential air conditioner in a large room.

Noise Level Note

The WAVE 3 operates at approximately 44dB to 58dB.

The lowest noise rating generally applies under reduced-load or Sleep Mode conditions.

Noise may increase when:

• The compressor operates at higher output
• Maximum fan speed is selected
• The unit is heating or cooling rapidly
• The exhaust duct is restricted
• The unit is positioned on an uneven surface
• The air filters or vents require cleaning

IPX4 Protection Note

The WAVE 3 carries an IPX4 water-resistance rating.

This means the unit is designed to resist splashing water under specified test conditions.

It is not waterproof and must not be:

• Submerged in water
• Left exposed to heavy rain
• Operated in standing water
• Cleaned with a pressure washer
• Stored outdoors without protection
• Used with wet electrical plugs or cables

Refrigerant Safety Note

The WAVE 3 uses R290 refrigerant.

R290 is a flammable refrigerant and must be handled according to the safety instructions.

Do not:

• Pierce or damage the refrigerant circuit
• Expose the unit to flames or excessive heat
• Attempt unauthorised refrigerant repairs
• Operate a visibly damaged unit
• Store the product near ignition sources

Refrigerant servicing should be completed only by an appropriately qualified technician.

Transport and Storage Note

Before moving or storing the WAVE 3:

• Switch the unit off
• Disconnect all power sources
• Drain accumulated water
• Disconnect the exhaust duct
• Keep the unit upright
• Do not tilt, overturn or drop the unit
• Allow the unit to settle upright before operating it after transport
• Store it in a dry and ventilated location

The WAVE 3 weighs approximately 15.6kg without the Add-On Battery.

The combined weight with the WAVE 3 Add-On Battery is approximately 25.3kg.

Recommended Use Cases

• Caravans and camper vans
• Motorhomes and RVs
• Camping tents with suitable ventilation
• Overlanding setups
• Cabins and small off-grid spaces
• Compact bedrooms
• Home offices
• Mobile workspaces
• Workshops
• Temporary accommodation
• Outdoor event support areas
• Emergency cooling or heating
• Load-shedding climate control when paired with compatible battery power
• Pet areas with appropriate monitoring and supervision

Performance and Reliability Features

• 6100 BTU cooling supports fast temperature reduction
• 6800 BTU heating provides portable warmth
• 16°C to 30°C temperature range supports year-round use
• 330m³/h airflow supports circulation in compact spaces
• Sleep Mode from approximately 44dB supports quieter operation
• Automatic Function adjusts operation according to temperature
• Dehumidification Function helps manage humid conditions
• Pet Care Function supports app-based temperature monitoring
• Wi-Fi and Bluetooth connectivity provide remote control
• IPX4 rating supports use in suitable outdoor and mobile environments
• Multiple power options support home, vehicle and off-grid use
• 24-month limited warranty provides manufacturer support

What’s in the Box

• 1 × EcoFlow WAVE 3 Portable Air Conditioner
• 1 × Insulated Exhaust Duct
• Exhaust Duct Adapter Cover A
• Exhaust Duct Adapter Cover B
• Exhaust Duct Adapter Cover C
• 1 × Drain Pipe
• 1 × Cable Winder
• 1 × Duct Size Template
• 1 × Quick Start Guide
• Safety instructions
• Warranty card

The EcoFlow WAVE 3 Add-On Battery, WAVE 2 Add-On Battery, portable power station, solar panel, Alternator Charger and other accessories are sold separately unless specifically included in a bundle.

Warranty

The EcoFlow WAVE 3 carries a 24-month limited warranty in South Africa.

Warranty coverage is subject to:

• Valid proof of purchase
• Correct installation and operation
• Use according to EcoFlow instructions
• Use with approved accessories
• No unauthorised modification or repair
• Compliance with the official EcoFlow warranty policy

Damage caused by misuse, incorrect storage, impact, water ingress beyond the IPX4 rating, improper transport, unauthorised repair or unsupported accessories may not be covered.
