Synology HAT3300-4T 4TB 3.5" SATA NAS Hard Drive

The Synology HAT3300-4T is a 4TB Plus Series 3.5-inch SATA hard drive designed for reliable 24/7 storage in compatible Synology systems. It features CMR technology, a SATA 6Gb/s interface, 5,400 RPM rotational speed, 256MB cache and typical sustained transfer speeds of up to 202MB/s.

Product Description

The Synology HAT3300-4T 4TB Plus Series Hard Drive is designed for dependable storage, backup, file sharing and everyday data management in compatible Synology NAS systems.

Built for continuous operation in home, small office and multi-user storage environments, the drive uses Conventional Magnetic Recording technology to provide consistent write performance throughout its operating life.

The HAT3300-4T features a SATA 6Gb/s interface, 5,400 RPM rotational speed, 256MB cache and a typical maximum sustained data transfer speed of up to 202MB/s.

With a 180TB per year workload rating and a 1 million-hour MTBF rating, the drive is designed to support demanding NAS storage workloads. Synology Plus Series drives undergo more than 500,000 cumulative hours of compatibility and stress testing for reliable operation in Synology systems.

Firmware updates can be performed directly through Synology DiskStation Manager, helping simplify drive maintenance without requiring disk removal or third-party firmware tools.

Please note: This product is an internal 3.5-inch SATA hard drive. A Synology NAS enclosure is not included.

Key Features

• 4TB internal NAS hard drive
• Designed for compatible Synology NAS systems
• 3.5-inch hard drive form factor
• SATA 6Gb/s interface
• 5,400 RPM rotational speed
• 256MB cache
• Up to 202MB/s typical sustained data transfer speed
• Conventional Magnetic Recording technology
• Designed for reliable 24/7 storage operation
• 180TB per year workload rating
• 1 million-hour MTBF rating
• Synology Plus Series drives undergo more than 500,000 cumulative hours of testing
• Firmware updates supported through Synology DSM
• Suitable for storage, backup, file sharing and multi-user workloads
• Three-year limited warranty

Specifications

• Product Type: Internal NAS Hard Drive
• Capacity: 4TB
• Form Factor: 3.5-inch
• Interface: SATA 6Gb/s
• Sector Size: 512e
• Drive Design: Air-sealed
• Recording Technology: Conventional Magnetic Recording
• Rotational Speed: 5,400 RPM
• Cache: 256MB
• Maximum Sustained Data Transfer Speed: Up to 202MB/s typical
• Mean Time Between Failures: 1,000,000 hours
• Workload Rating: 180TB per year, data written and read
• Active Idle Power Consumption: 3.96W typical
• Random Read/Write Power Consumption: 4.85W typical
• Supply Voltage: 12V and 5V
• Operating Temperature: 0°C to 65°C
• Non-operating Temperature: -40°C to 70°C
• Operating Humidity: 5% to 90% RH, non-condensing
• Non-operating Humidity: 5% to 95% RH, non-condensing
• Dimensions: 20.20 × 101.85 × 147mm
• Weight: 490g

Compatibility Note

Please confirm that the Synology HAT3300-4T is listed as compatible with your specific Synology NAS or storage system before ordering.

Compatibility may vary according to the Synology system model, hardware revision, supported drive list and installed DSM version.

This is an internal 3.5-inch SATA hard drive and requires a compatible SATA drive bay. It is not an external USB hard drive.

The available capacity displayed by your NAS or operating system will be lower than the stated 4TB capacity because of formatting, storage calculations, system files, RAID configuration and other system requirements.

Actual transfer performance depends on the Synology system, RAID configuration, network connection, workload, settings and other installed drives.

MTBF is a statistical reliability value and is not a guarantee or estimate of the operating life of an individual hard drive.

Compatible Devices

Compatible Synology NAS and storage systems that officially support the Synology HAT3300-4T 3.5-inch SATA hard drive

Recommended Uses

• Compatible Synology NAS systems
• Centralised file storage
• Home and small office backup
• Shared business data
• Personal cloud storage
• Media and document libraries
• RAID storage configurations
• Multi-user file access
• Continuous NAS storage workloads
• Synology storage capacity expansion

What’s in the Box

• 1 × Synology HAT3300-4T 4TB 3.5" SATA NAS Hard Drive
